Trane 2–3 Ton 24000–36000 BTU 4MXC 4 Way Cased Coil 4MXCB004AC6HC
Trane 2 – 3 Ton 24000 – 36000 BTU 4MXC Four Way Cased Coil 4MXCB004AC6HCA is equipped with Trane’s all-aluminum Comfort™ coil. The unit is tested & tried to ensure minimum leaks. The high-quality construction of this 36000 BTU coil unit complements any heating and air conditioning system components.
Trane 2 – 3 Ton 24000 – 36000 BTU 4MXC Four Way Cased Coil 4MXCB004AC6HCA is equipped with Trane’s all-aluminum Comfort™ coil. The unit is tested & tried to ensure minimum leaks. The high-quality construction of this 36000 BTU coil unit complements any heating and air conditioning system components. Apart from that, the 4MXCB004AC6HCA Comfort™ Coil unit very easy to clean and maintain.
The 24000 – 36000 BTU 4MXC 4 Way cased coil unit is equipped with a 100% foil-backed insulation. This insulation allows you to have a quiet operation experience. Besides, the 2 way noncorrosive drain pan doesn’t let water collect/sit for long. Lastly, the 2 ton to 3 ton 36000 BTU unit is covered with a durable finish. This premium finish protects the cased coil unit from rust & corrosion.
Features of Trane 2 – 3 Ton 24000 – 36000 BTU 4MXC Four Way Cased Coil 4MXCB004AC6HCA
- Two way noncorrosive drain pan ensure water doesn’t sit
- The durable painted finish increases protection from rust & corrosion
- All-aluminum Comfort™ coil reduces leaks
- Rust & corrosion resistant coil unit
- 100% foil-backed insulation that enables quiet operation
- Comfort™ Coils are easy to clean
Specifications of Trane 2 – 3 Ton 24000 – 36000 BTU 4MXC Cased Coil 4MXCB004AC6HCA
Cased Coil Specifications
Tonnage 2 – 3 Tons
Capacity 24000 – 36000 BTU
Coil Type Cased
Configuration Upflow, Downflow, Horizontal Left & Right
Refrigerant control Piston
Lineset Connection Type Sweat
Maximum Airflow
Upflow 1250 CFM
Horizontal Left 1200 CFM
Downflow 1050 CFM
Horizontal Right 1250 CFM
Cased Coil Dimensions
Gas Connection 3/4 Inches
Liquid Connection 3/8 Inches
Drain Connection 3/4 Inches
Coil Height 20 Inches
Coil Width 17.5 Inches
Coil Depth 21 Inches
Cased Coil Weight
Coil Weight 43 Pounds
